Eagle-II Residential Swing Gate Operator

Save $100
EagleSKU: Eagle-II | Condition: New

Price:
$1,199 $1,299
FREE SHIPPING in the US

Description

Free Eagle EG654 Keypad ($119 value) with the purchase of this operator.

Residential Gate Operator

Gate Capacity: 14’ 400 lbs

The Eagle-II is Manufactured with the same quality and engineering as our larger commercial and industrial models, the Eagle-II swing gate operator is designed for residential applications and is built for gates up to 14 feet or 400 lbs. It features the state of the art AC mini control board and comes with a swivel arm hardware that includes a quick-release mechanism for operation during a power outage. This model is equipped with a 1/2 horsepower motor continuous duty AC motor, a quiet gearbox and quality components throughout. The Eagle-II is backed by our best in class 5 year warranty.

Standard Features

  • 2-Wire Master/Slave with Global Inputs
  • Open/Close Delay
  • Motor Brake
  • 24 VDC Output for MAG Lock
  • 24 VAC Auxiliary Power Output
  • Auto-Close Timer (1-60 sec.)

Operating Classification

  • Class I

Warranty

  • 5-Year Limited (Residential)

Mechanical

  • Drive Chain: #50 Nickel Plated
  • Gear Reducer: Size 50 & 40
  • Swing Arm with No-Pinch Design
  • Cover: All-Weather/UV Resistant (HDPE)
  • Chassis: Zinc Plated Steel to Resist Corrosion
  • Power Disconnect (1/2 HP)

Manual Release

  • Quick Release Lever

Power

  • 1/2 HP Continuous Duty AC
  • 115 VAC @ 60 HZ 5.7 AMP

Hardware

  • No-Weld Swing Arm Assembly
  • Audio Alarm
  • Pre-Wired Receiver Terminal

Gate Capacity & Operation

  • Maximum Gate: 14 ft & 400 lbs
  • 18 seconds(approx.) to open (0-90 degrees)
  • Rated Continuous Duty

Dimensions

  • 20″ (h) x 16 1/2″ (w) x 15″ (d)

Shipping Weight

  • Eagle-II: 90 lbs

Installation Instructions

  • Easy to follow instructions. Available in Spanish. Las instrucciones de la instalación disponibles en Español.
Accessories Included:
  • 2 Remotes
  • 1 Receiver
  • 1 EG111 Photo Eye Sensor

Downloads

  • Spec Sheet

  • Installation Manual
